Performance
Technology and processing from Germany
Shape “▽” double motor drive, reduce the ground area, main axis bearing capacity is more uniform, extend the service life
The "flywheel effect" of large belt wheels is more energy -saving;
Exquisite processing and reasonable design, higher granules efficiency
Overall -casting machine base, running more smoothly
Granules door is made of stainless steel material
Unique oil injection device, more convenient lubrication
The main bearing uses "SKF" brand bearing
Nearly perfect structure, high standard material selection, ultra -low maintenance cost
Equipped with safety interlocking device to protect personal safety
Optional single -layer, multi -layer, dual axis differential or combined conditioning equipment.
Technical Description
| Product Model | 9KLH-250D | 9KLH-304D | PMV-350D | PMV-420D | PMV-520D | PMV-660D |
| Main Power(kw) | 22 | 30/37 | 30×2 | 55×2 | 75×2 | 90/110×2 |
| Feeding Power(kw) | 0.75 | 0.75 | 0.75 | 1.5 | 2.2 | 2.2 |
| Modulation power(kw) | 1.5 | 1.5 | 3 | 7.5 | 15 | 15 |
| Capacity(t/h) | 0.5-1.5 | 2-4 | 4-6 | 8-12 | 13-18 | 18-25 |
| Note: The above output refers to the production livestock and poultry ∅ 3.5mm ring die. | ||||||
